Multi-Modality Testing

diptest.py

import itertools
from dataclasses import dataclass
from typing import Tuple

import numpy as np
from diptest import diptest

MEAN = 18.75
STDDEV = 5.647


@dataclass
class Pair:
    """
    Data shown represent one of two values. Since we cannot tell
    which of the two values the frequency is associated with,
    we need to be able to check all combinations of both values.
    """
    start: int
    freq: int

    def __iter__(self):
        """
        Begin an iteration
        """
        self.count = 0
        return self

    def __next__(self):
        """
        Returns a list of length `freq`, returning
        all combinations of the two possible values.
        For example, Pair(1,2) would return [1,1], then [1,2] and then [2,2]
        """
        n = self.count
        m = self.freq - self.count
        if m < 0:
            raise StopIteration
        self.count += 1
        a = [self.start]
        b = [self.start+1]
        return a*m + b*n


@dataclass
class Data:
    """
    A way to represent the data (just a tuple of ints)
    """
    ls: Tuple[int]

    def mean(self, sf: int):
        """
        Returns the mean to the appropriate number of significant figures
        """
        return float(round(np.mean(self.ls), sf))

    def std(self, sf: int):
        """
        Returns the standard deviation to the appropriate number of significant figures
        """
        return float(round(np.std(self.ls), sf))

    def matches(self, mean=MEAN, std=STDDEV):
        """
        Test if the data matches the mean & std given
        """
        return self.mean(2) == mean and self.std(3) == std

    def test(self):
        """
        Test if the data is multi-modal or not
        """
        dp = diptest(np.array(self.ls))
        return {"stat": dp[0], "p": dp[1]}


@dataclass
class PairList:
    ls: Tuple[Pair]

    def __init__(self, *args):
        self.ls = tuple(args)

    def __iter__(self):
        self.iters = itertools.product(*self.ls)
        return self

    def __next__(self) -> Data:
        return Data(tuple(y for x in next(self.iters) for y in x))


# Data taken from the plot
datapairs = PairList(
    Pair(1, 1),
    Pair(3, 2),
    Pair(5, 1),
    Pair(15, 3),
    Pair(17, 5),
    Pair(19, 12),
    Pair(21, 9),
    Pair(23, 5),
    Pair(25, 2)
)

sig = 0
nsig = 0

for gen_data in datapairs:
    if gen_data.matches():
        dp = gen_data.test()
        if dp["p"] < 0.05:
            sig += 1
        else:
            nsig += 1
print(f"{sig = } <=> {nsig=}. Prop: {sig/(sig+nsig)}")
